I have been involved with hundreds of projects in one capacity or another where I’ve designed or commissioned HVAC systems. With only a few exceptions, it’s been my experience that ductwork is never installed exactly as drawn. Most of the time it’s close. Usually, this is due to a lack of coordination during design requiring in-field modifications or a lack of detail when it comes to equipment hookups. We all expect design engineers to have their designs perfectly coordinated and their equipment details to be exact. I was on the design side for more than 10 years and I can tell you that there is never enough fee or enough time in the design schedule for that to be a reality. Until that changes, we’d all better expect field modifications.

Lighting controls in commercial building have undergone a transformation in the last few years. The simple wall switch (or no switch!) has given way to occupancy sensors and vacancy sensors with passive infrared (PIR) and ultrasonic motion detection. Additionally, photocell sensors have been added for daylighting control. The intent of these advances in lighting controls is to ensure that interior light fixtures are only on when occupants are in a space and natural light levels are inadequate. In my view, we still have a long way to go to achieve this intent across the building design and construction industries.

I’m finding that the lighting energy requirements of ASHRAE/IESNA Standard 90.1 are less efficient than standard practice in the field. Standard 90.1 is the “Energy Standard for Buildings Except Low Rise Residential Buildings” and is often used by design professionals as the de facto energy code. The 2013 edition of the Standard has just been released and amazingly, the allowed lighting power density (LPD)¹ has increased since 2004 for several common space types, such as private offices, and for multiple building types, including offices and parking garages. Yet, since 2004 the energy efficiency of lighting equipment has improved dramatically. Why is the code going the wrong way?

In facilities management and building owner circles, Preventative Maintenance (PM) contracts are seen (at least in theory) as a good way to outsource the routine maintenance of some/all building equipment. As an example, a HVAC PM contractor could change air filters in air handlers and terminal equipment, replace belts, drain and fill cooling tower systems before and after the winter, grease bearings, possibly perform chemical treatment of hydronic or condenser water systems, and perform other routine service tasks. The frequency and scope of service varies from contract to contract—some items are replaced on an as-needed basis—for example, belts may be inspected at some predefined interval, and replaced as wear is evident. Other tasks may be scheduled as a standard interval—such as filter changes. And still other tasks may be triggered by variables such as climactic conditions—for example, when a cooling tower is drained for the winter or refilled in the springtime.

Throughout the commissioning process, we often find issues with accessibility to equipment, whether it be a heat pump above a ceiling grid or an air handler in a mechanical room. Accessibility to all aspects of a unit is frequently overlooked during the design and construction process. Having adequate clearance is important for the building owner and the maintenance faculty.

HVAC control sequences of operation have a direct impact on the effectiveness and efficiency of building systems. When specified and programmed correctly, control sequences of operation enable HVAC systems to efficiently meet the loads placed upon them. When designed and implemented incorrectly, sequences of operation can cause HVAC systems to either fail to meet building loads or waste energy (e.g. a system trying to simultaneously heat and cool the same space). In order for HVAC systems to operate at their peak efficiency, the control sequences of operation need to be appropriate for both the equipment type and the application.

With the hot, humid weather behind us, it’s time to review the status of our HVAC systems and ensure they are prepared to operate efficiently in the shoulder season and winter months.

Air source heat pumps have been around for a long time. Especially in climates more moderate than the northeastern United States, they have been the primary space conditioning equipment for a large fraction of homes. Relatively recent developments in high efficiency air-source heat pump technology have pushed heat pumps into colder climate zones such as the northeast US, and have pushed the technology into different end uses. Over the past several years, water-source heat pumps for domestic hot water heating applications have entered the marketplace in the US. Five years ago, heat pump water heaters (HPWH) were difficult to find; now, most major water heater brands have a heat pump water heater option.

I recently had the opportunity to familiarize myself with the Energy Star Portfolio Manager system, which is a free online tool to track and analyze a building’s energy usage via benchmarking. Benchmarking has been previously blogged about by Ben Fowler and Jennifer Chiodo. Certain property types (e.g., hospital, medical office building, office building, etc.) are eligible for an Energy Star score when you have at least 12 months of utility data.
